SU-8光刻胶系列产品

Gersteltec 提供多种SU-8光刻胶，适用于不同的材料和应用环境。我们提供的光刻胶是配好的成品（ready-to-use），可以直接使用在各种膜片，涂料，墨水或者溶液。functional SU-8系列产品可用于各种微型器件的制作。SU-8 采用IBM研发的环氧树脂. SU-8可应用于MEMS, MOMES, UV-LIGA 等操作中，固定可采用多种光源，比如 X-ray, UV 和 e-Beam。
订购信息：

SU-8
Products	Processing	Size
GM1010  for layers between 0.2-0.8µm	spray
		500ML
		1L
GM1040  for layers between 0.8-10µm	Spin, spray, Inkjet
		500ML
		1L
GM1050 for layers betwwen 3-8µm	Spin, Inkjet
		500ML
		1L
GM1060 for layers between 10-50µm	Spin, Inkjet
		500ML
		1L
GM1070 for layers between 50-250µm	Spin, Inkjet
		500ML
		1L
GM1075 for layers between 250-350µm	Spin, Inkjet
		500ML
		1L



SU-8-FunctionalPolymer
Name	Functional	Specials parameters	Applications
GLM 2060	Isolated, Low-Stress Passivation layer	Low thermal expansion CTE 27 (ppm/K) low temperature processing 95-120°C	Ink jet (nozzle), high mechanical resistance parts
GMPI 10xx	Bio
Acrylate	Tailor made product	Microfludic application
GCM3060	Conductive	Conductivity 100-1000000 (S/m)	Electrically conductive electrodes, RF screening, antistatic material, interconnect packaging
GMC 10XX	Filter , colorfilter array (CFA), Color filter mosaic (CFM).	Red, Blue, Yellow, Violet, Green	Colored SU-8 photoresist (red, blue, violet, yellow, green, black, and other…) Applications: Marking, filter in the UV-Visible-NIR range
GMCD 10XX	Filter,disply, Hide defect	Black
GM1010 GM1020	For E-Beam Lithography
GCM3060	For Proton Beam Lithography
GM10xx	For InkJet deposition
GLMPI2075	For Laser Lithography
GMCNT	SU8-Carbon Nanotube (CNT). Tailor made Products Isolated SWCNT. Tailor made Products Conductive MWCNT. Tailor made Products
Other products: Stripper/SRGM 500 ml Developer/DRGM 500 ml Adhesion Promoter / ADP
